BASIC Trailer- Mounted Batch Mixer, consist of engine, transfer case, batch tank, mixing system, hydraulic system, electrical control system etc. This unit is used to mix slurry and send the mixed slurry to the pump unit continuously when carry out cementing construction.

The engine for the BASIC Batch Mixer is a Caterpillar 3406 electronic wet exhaust engine, 425 Bhp (317 KW).The engine is connected by a manual drive line and clutch assembly to Harrisburg 6X8 centrifugal pump designed to recirculate the complete volume of the mixing tank to a very high rate. The 4″ figure 206 hammer union on the inlet is connected to a vortex on the discharge of the pump. This is designed to allow materials to be moved to the unit by air or pump and uniform

The unit is mounted with a detachable hopper to mix dry or liquid chemicals. Engine shall always be air started. Engine includes air compressor and air reservoir. Unit includes an integrally mounted 132- gallon fueltank and includes spark arrestor and stainless-steel exhaust manifold. Diesel engine option is rated for safe area. No option is available for a Zone 2 dieselengine package
